Functional features: 1. Electric vibration knife and gun head, strong power, high vibration frequency, up to 25,000 times per minute.
2. The transmission system of the cutting machine adopts imported linear guide rail, rack and gear, and the cutting precision reaches zero error to and from the origin.
3. The machine has function head optional: vibration knife, round knife, V scissors, V knife, creasing wheel and drawing pen, etc.It can cut asbestos gasket, rubber gasket, honeycomb board, plastic corrugated board, plastic hollow board, grey board, composite material, rubber board, pearl cotton and EVA board etc.
4. Programmable multi-axis motion controller, with stability and maneuverability reaching the leading technical level at home and abroad.
5. The machine table is made of fiberboard imported from the United States, with good air permeability, durable and not easy to deform.
6. Adopt the upper computer control system completely developed by ourselves, which is able to learn and operate humanized interface, and support remote teaching, remote maintenance and remote upgrade, so that customers can use more worry free.
7. Can be connected to any CAD software, widely used in gasket industry, clothing industry, composite materials, luggage industry, automobile industry, advertising and printing industry, decoration industry, furniture industry and other industries of drawing and cutting.
8. Optional loading rack and automatic feeding device.
Table of Technical Information on Intelligent feed cutting machine | ||||
Technical information/model | JD-ASF-1410 | JD-ASF-1813 | JD-ASF-2516 | JD-ASF-2520 |
Operation properties | Computer operation and cutting machines can be used simultaneously for quick data transmission capable of continuous operations | |||
Cutting speed | Maxi 1500mm/s | |||
Cutting Thickness | 0.2-60mm | |||
Cut materials | Corrugated materials, sponge and foam board, lvory cardboard, gray paper, corrugated paper, plastic sheets, composite materials and leather materials maximum cutting thickness at 30mm | |||
Number of pens | 8 different groups of strokes, half blades, full blades and pressure wheel setup | |||
Positioning device | Automatic camera positioning | |||
Method for fixing paper | Vacuum absorption | |||
Cutting tolerance | ±0.2mm | |||
Repeat accuracy | ≦0.05mm | |||
Minimum circle | ≧5mm diameter | |||
Transmission interface | Ethernet port | |||
Format compatible | Compatibility format AI software, Autocad, Coreldraw and all box software | |||
Direcive system | HP-GL和GP-GL HP-GL and GP-GL | |||
Digital control panel | Liquid crystal display and contact button | |||
Transmission materials | Gear-rack drive | |||
Supply voltage | AC 220V 380V ±10%，50HZ | |||
Motor type | servo motor | |||
Vibration blade | Vibration cutter head motor at 25000rpm | |||
Cutting area | 1400mm*1000mm | 1800mm*1300mm | 2500mm*1600mm | 2500mm*2010mm |
Overall dimension | 2300*1700*1220mm | 2700*2000*1220mm | 3400*2300*1220mm | 3400*2710*1220mm |
